Sun SiteScale Model Sun is a 36-inch diameter sphere suspended above Paseo Colorado's Central Circle, with an information pedestal at ground level.Appearance is reflective of its imposing scale and dazzling brilliance. |
SUN LOCATION IN |
ORIGINAL STRUCTURE |
Mercury SiteImaginative Sculpture:Sphere is 1/2 polished black granite and 1/2 cast bronze. Surface texture of bronze is based on planet as currently photographed and mapped. Eighteen inches diameter. Appearance is reflective of its known and unknown portions. Base is a Canadian white boulder with black (nickel) veins. Approximate height with sphere is 4 feet 6 inches. Sphere is fixed to boulder base. Base is attached to footing at ground. Planet Model: Pre-cast, uniquely finished concrete. Informational insets and title plaque in stainless steel, copper or brass, with etched enamel infill. Unique planet orbital disk depicting the equatorial plane and the scale model planet on the angle of its polar axis. Planet Model and Imaginative Sculpture Planet are on concrete footings connected by a concrete arc with brass inset directional arrows and planet name. |
MERCURY LOCATION ON PASEO GROUNDS (ORIGINAL CENTRAL PARK LOCATION SHOWN) |
MERCURY SITE STRUCTURE |
Venus SiteImaginative Sculpture:Sphere material is cast red glass and green verdigris copper. 32-inch diameter. Appearance is reflective of its volcanic past and its hellish surface. Base is a cylindrical stainless steel stand inclined at angle of planet's polar axis. Sealed ball-bearing internal mechanism. Approximate height with sphere is 4 feet 6 inches. Sphere rotates manually in clockwise direction. Planet Model:(Same description as for Mercury Site above) |
VENUS LOCATION ON PASEO GROUNDS (ORIGINAL CENTRAL PARK LOCATION SHOWN) |
VENUS SITE STRUCTURE |
Earth SiteImaginative Sculpture:Sphere material is cast blue glass with a visible core and a bronze map of Pangea. 32-inch diameter. Appearance is reflective of plate tectonics and liquid water. Base is a cylindrical stainless steel stand inclined at angle of planet's polar axis. Sealed ball-bearing internal mechanism. Approximate height with sphere is 4 feet 6 inches. Sphere rotates manually in clockwise direction. Base is attached to footing at ground. Planet Model:(Same description as for Mercury Site above) |
EARTH LOCATION ON OR NEAR PASEO GROUNDS (ORIGINAL CENTRAL PARK LOCATION SHOWN) |
EARTH SITE STRUCTURE |
Mars SiteImaginative Sculpture:Sphere material is cast iron. Surface texture is based on planet as currently photographed and mapped. 24-inch diameter. Appearance is reflective of its highly studied surface and red coloration. Base is a "Desert Red" boulder. Approximate height with sphere is 4 feet 6 inches. Sphere is fixed to boulder base. Base is attached to footing at ground. Planet Model:(Same description as for Mercury Site above) |
MARS LOCATION MANY POSSIBLE SITES (ORIGINAL CENTRAL PARK LOCATION SHOWN) |
MARS SITE STRUCTURE |
Jupiter SiteImaginative Sculpture:Sphere material is integrally colored, uniquely stained and polished concrete. Predominantly rust, cream, and green colored.. Surface texture is based on planet as currently photographed and mapped. 54-inch diameter. Appearance is reflective of its scale and of its luminous, swirling visible surface. Base is a concrete footing. Approximate height of sphere is 54 inches. Sphere is directly attached to footing at ground. Planet Model:(Same description as for Mercury Site above) |
JUPITER LOCATION |
JUPITER SITE STRUCTURE |
Saturn SiteImaginative Sculpture:Sphere material is laminated, milled limestone and marble. Predominantly buff, gold, and beige colored. "Rings" of stainless steel with round beveled edges and enamel infill. 40-inch diameter. Reflective of its striations and characteristic rings. Base is a concrete footing. Approximate height of sphere is 54 inches. Sphere is directly attached to footing at ground. Planet Model:(Same description as for Mercury Site above) |
SATURN LOCATION ONE POSSIBLE SITE IS NEAR PASADENA UNIFIED SCHOOL DISTRICT HQ (ORIGINAL BROOKSIDE PARK LOCATION SHOWN) |
SATURN SITE STRUCTURE |
Uranus SiteImaginative Sculpture:Sphere material is cast blue glass with a visible axis bar. 36-inch diameter. Reflective of its unique axial rotation and translucent surface. Base is a stainless steel yoke supporting the horizOntal axis. Sealed ball-bearing internal mechanism. Yoke attaches to a rough-hewn stone on concrete footing. Approximate height with sphere is 4 feet 9 inches inches. Sphere rotates manually in counter-clockwise direction. Planet Model:(Same description as for Mercury Site above) |
URANUS LOCATION SOME POSSIBLE LOCATIONS ARE AT CALTECH (ORIGINAL PASADENA CITY COLLEGE LOCATION SHOWN) |
URANUS SITE STRUCTURE |
Neptune SiteImaginative Sculpture:Sphere material is milled Blue Pearl Granite, inset with stainless steel arrows. 36-inch diameter. Reflective of its coloration and its furious winds. Base is a cylindrical stainless steel stand inclined at the angle of the planet's polar axis. Sealed ball-bearing internal mechanism. Approximate height with sphere is 4 feet 6 inches inches. Sphere rotates manually in counter-clockwise direction. Planet Model:(Same description as for Mercury Site above) |
NEPTUNE LOCATION ONE POSSIBLE LOCATION IS WEST OF ROSE BOWL (ORIGINAL VICTORY PARK LOCATION SHOWN) |
NEPTUNE SITE STRUCTURE |
Beyond Pluto SiteImaginative Sculpture:Sphere material highly polished stainless steel. 18-inch diameter. Appearance is reflective of its surroundings (literally, JPL and riparian environment) and the cold and unknown nature of the many Pluto-like objects in the Kuiper Belt. Base is an Imperial Black granite boulder. Approximate height with sphere is 4 feet 6 inches inches. Sphere is fixed to boulder base. Bases is attached to footing at ground. Planet Model: (Same description as for Mercury Site above) |
LOCATION MANY POSSIBLE LOCATIONS (HAHAMONGNA PARK LOCATION SHOWN) |
SITE STRUCTURE |
